Keypad mounting *template, Keypad mounting template – Impulse PCW-5181 User Manual
Page 79
Chapter 6 - Hardware Reference
6-3
Keypad Mounting *Template
*CAUTION - this is scaled-down version of the keypad template. Use this drawing only for
dimensions and locations of mounting holes. The actual template is included with your keypad and
may also be found at:
KEYPAD MOUNTING TEMPLATE
E
M
B
CUT THESE HOLES FOR
6/32 CAPTIVE MOUNTING.
3/16" CLEARANCE HOLES (4)
CUT THESE HOLES FOR
M3.5 CAPTIVE MOUNTING.
CUT THESE HOLES FOR
BALL-HEAD REMOVABLE MOUNTING.
5/32" CLEARANCE HOLES (3)
3/16" CLEARANCE HOLES (4)
CAUTION: Your Keypad will be damaged if mounting
screws extend more than 0.2 inches into the keypad.
