Impulse PCW-5181 User Manual
Page 76
Chapter 5 - Configuring Impulse with an IDC Keypad
5-24
UNIT#
This menu allows you to configure the unit number for use in RS232C daisy chains or RS485 buses.
The valid range for unit numbers is 1 - 99.
1.
Using the numeric keys, enter the desired unit number for the drive.
Very Important! - Send the File to the Drive
When all setup parameters have been configured and the motor has been probed, use the COPY
menu (COPY > FRM PAD) to send the project file to the drive.
> UNIT#
EDIT
- - - Unit Number - - -
1
