Chapter 5 - Configuring Impulse with an IDC Keypad
5-17
4. Press ESC.
5. Press YES (F1) to save the new settings, or press NO (F3) to
restore the original settings.
Configure X-SM2 and X-SM3 using the same procedures as X-SM1 (i.e. VALUE, TEST SPEED,
and FINE).
ADVANCED SETUP
The following parameters must be configured in the ADVANCED SETUP sub-menu:
Configuring Anti-Resonance Gain
GAIN 1
This option allows you to configure the anti-resonance gain (#1) between 0 and 32,767. Setting gain
at 0 disables the anti-resonance feature, regardless of the GAIN2 setting.
1. Press GAIN1 (F1).
2. Using numeric keys, enter a gain of between 0 and 32,767.
3. Press ESC.
GAIN2 (required only if GAIN1 was configured)
This option allows you to configure the anti-resonance gain (#2) between 0.1and 25.0.
1. Press GAIN2 (F2).
2. Using numeric keys, enter a gain of between 0.1 and 25.0.
3. Press ESC.
Keep New Settings?
YES NO
ANTI-RESONANCE (A-RES)
GAIN 1
GAIN 2
Profiling (PRFILE)
MULTI (Multistepping)
DYNSM (Dynamic Smoothing)
DSGAIN (Dynamic Smoothing Gain)
STOP RED TIMEOUT (I-STOP)
IDLE MODE REDUCTION (I-IDLE)
TIMEOUT
%RED
STALL DETECTION (STALL)
DISABLED
ENABLED
> SETUP > ADVNCE > EDIT
-
↑↑↑↑
ADVANCED SETUP
↓↓↓↓
-
A-RES DYN-SM I-STOP
-
↑↑↑↑
ADVANCED SETUP
↓↓↓↓
-
I-IDLE STALL
> SETUP > ADVNCE > A-RES EDIT
- - ANTI-RESONANCE - -
GAIN1 GAIN2
- Anti-Res Gain #1 -
0
- Anti-Res Gain #2 -
0
