Chapter 6 - Hardware Reference

6-13

P/K 31, 32, 33Step Motor Specifications

EQ and EM Encoder Cables

Quick Disconnect Motor Cable

Motor Dimensions

Signal

*Pin

Color

Wire Color

Signal

Motor

D

K

T

X

LMAX

A+

B

Red

Red w/ Black

B-

P31

.5000

.1250

.555

(3.70)

4.44

A-

C

Pink/Purple

Red w/ White

B+

P32

.5000

.1250

.555

(5.22)

5.96

B+

N

Green

Green

*GND

P33

.6250

.1875

.705

(6.74)

7.48

B-

P

Blue

Red w/ Yellow

A-

Z+

M

Yellow

Red

A+

Z-

U

Orange

*Connect shield of gray QF3-12

cable to GND.

+5V

K

White

COM

T

Black

Shld

---

---

*EQ Cable only.

Brown-NC

Electrical Specs.

P31V

P32V

P33V

Continuous Stall Torque oz-in [N-m]

450 [3.2]

920 [6.5]

1260 [8.9]

Recommended Current/Phase Amps

2.9

3.3

4.0

Inductance mH

14

30

25

Max. Winding Temperature °F [°C]

212 [100]

212 [100]

212 [100]

Mechanical Specs.

P31V

P32V

P33V

Rotor Inertia oz-in-sec

.0202

.038

.0567

Axial Shaft Load lbs [N]

305 [1350]

305 [1350]

305 [1350]

Radial Shaft Load @ 0.5 inches lbs [N]

665 [285]

665 [285]

110 [489]

Motor Weight lbs [kg]

5

8.4

11.9

Step Angle (full step) degrees

1.8

1.8

1.8

IDC Quick Disconnect Cable

P/N QF4-12 (18AWG)

EQ

Encoder

Cable

IDC Motor Wiring

Series

YELLOW

WHT/YEL

WHT/RED

RED

SHIELD

BLACK

WHT/BLK

WHT/ORG

ORANGE

Parallel

YELLOW

WHT/RED

RED

WHT/YEL

SHIELD

BLACK

WHT/ORG

ORANGE

WHT/BLK
