Chapter 5 - Configuring Impulse with an IDC Keypad

5-19

Configuring Idle Mode Current Reduction Parameters

Use this option to set the Idle Mode current-reduction parameters (TIMEOUT and %RED).

TIMEOUT sets the Idle Mode current reduction period in seconds. When the TIMEOUT period has
elapsed, the commanded motor current will be reduced by the percentage defined in EDIT > SETUP
> ADVNCE > I-IDLE > %RED. Full current is restored on the next commanded step. The valid
range for the timeout is 0 to 3600 seconds. Setting the timeout to 0 disables the Idle Mode feature
and the display will read “Off”.

%RED (percentage of reduction) sets the percentage of current reduction that occurs after the Idle
Mode TIMEOUT has expired. The valid range for percentage of reduction is 0 to100%. The Idle
Mode reduction percentage takes precedence over the Stop Mode 25% reduction if both modes have
been enabled.

TIMEOUT

Press TMEOUT (F1).

Using the numeric and decimal keys, enter the desired
current-reduction period (seconds).

Press ESC.

%REDUCTION (required only if TIMEOUT was configured)

Press %RED (F2).

Using the numeric keys, enter the desired percentage of
reduction (no decimal).

Press ESC.

Configuring Encoderless Stall-Detection (OLSD™)

This option allows you to enable or disable the OLSD™ feature. OLSD™ becomes active at
velocities of 0.5 RPS and greater.

Using the up and down arrows, toggle to DISABLED or ENABLED OLSD™ .

Press ESC twice to return to the EDIT > SETUP menu.

> SETUP > ADVNCE > I-IDLE

EDIT

- IDLE MODE REDUCT -
TMEOUT %RED

- Idle Mode Tmeout -

Off

- Idle Mode %Redct -

> SETUP > ADVNCE > STALL

EDIT

- Stall Detection -

↑

DISABLED

↓↓↓↓
