Replacing fans and fan modules
Your server comes equipped with several cooling fans and fan modules designed to provide
sufficient airflow to keep your server running without overheating. These include:
■
A system fan module with four, dual-rotor multi-speed fans to cool the processors,
the memory, and the second and third hard drive bays (redundant when running low
voltage processors).
■
A single-rotor system fan to cool components in the full-height PCI zone, the power
distribution board and the first hard drive bay.
■
Two dual-rotor power supply fans to cool the power supply modules (redundant in
the 1+1 power supply configuration)
System fans
System fans are monitored by the Gateway Server Manager (GSM), the mini-Baseboard
Management Controller (BMC), and the Intel Management Module (IMM). All three
reporting entities use a different numbering system to flag individual fans for attention.
Individual system fan module fan numbers are indicated on the top of the processor air
duct. The first number in the pair is for the fan closest to the front of the server.
Caution
System fans are not hot-swappable. Before removing or replacing a
fan, you must first turn off the server and all peripheral devices
attached to the server, and remove the AC power cord(s) from the
power supply or wall outlet.
Processor fan
duct number
GSM
Mini-BMC System
Event Log
IMM System Event
Log
1A
1A
1B
40
1B
1B
1C
41
2A
2A
1F
44
2B
2B
20
45
3A
3A
21
46
3B
3B
22
47
4A
4A
1D
42
4B
4B
1E
43
(none)
PCI Fan
23
48
