System board, Connectors – Gateway 9415 User Manual
Page 11
6
www.gateway.com
System board
Connectors
Control panel
34-pin
Diskette
CPU 2 fan header
PCI riser slot
(low-profile)
PCI riser slot
(full-height)
I/O panel
Battery
Serial A
header
Intel Management
Module (IMM)
connector
SCSI
channel A
IPMB
SATA
ports
CPU
socket 1
CPU
socket 2
DIMM sockets
+12V CPU
power
Power
connector
Control panel
50-pin
ATA-100
connector
Control panel,
diskette, IDE -
100-pin
System fan
SCSI
channel B
CPU 1 fan header
ICMB
USB
header
USB
header
System fan
8510522.book Page 6 Wednesday, March 16, 2005 11:19 AM
