RX600 S5 Operating Manual 53
Hardware installation Connecting devices to the server
4.3 Connecting devices to the server
The connectors for external devices are on the front and rear of the server. The
additional connectors available on your server depend on the expansion cards
installed (e.g. optional SAS connector).
I
Some of the devices that can be connected may require special software,
e.g. drivers (see the documentation for the connected device).
Figure 8: Connectors on the front
On the front of the server are a video connector (1) and three USB
connectors (2).
I
The two video connectors on the front and rear (see figure 9 on page 54 )
can only be used alternatively; the connector not used is automatically
deactivated.
