RX600 S5 Operating Manual 139
Appendix: server specification
Drive bays
General system information
Operating Panel
Hard disk bay
configuration 8 x 2.5-inch hot-plug SAS
Accessible drive bays 1 x 5.25/0.5-inch for CD-RW/DVD
1 x 5.25/1.6-inch for backup devices
Notes accessible drives all possible options described in relevant system
configurator
Number of fans 8
Fan configuration hot-plug
Fan notes Different base units available: with 4 fans (non
redundant) or 8 fans (redundant)
Operating buttons On/off switch
NMI button
Reset button
ID button
Status LEDs System status (amber / yellow)
Identification (blue)
Hard disks access (green)
Power (amber / green)
At system rear side:
System status (amber / yellow)
Identification (blue)
Service display
(optional): ServerView Local Service Display (LSD)
