Hot-plug memory boards – FUJITSU PRIMERGY RX600 S5 User Manual
Page 115
RX600 S5
Operating Manual
115
CSS components
Hot-plug components
8.1.5
Hot-plug memory boards
V
CAUTION!
●
The actions described in this section may only be performed by
personnel with the appropriate technical training. (The device can be
seriously damaged if it is opened without authorization or if repairs
are attempted by untrained personnel.)
●
Please observe the safety information in
.
The system board has space for up to eight memory boards, each of which can
be equipped with up to eight memory modules. The slots for the main memory
are suitable for 2 GB, 4 GB, 8 GB and 16 GB DDR3 1066/1333 MHz memory
modules. This allows a maximum memory capacity of 1024 GB (with availability
of 16 GB memory modules).
A possible memory module fault is reported by the CSS indicator lighting up on
the front and rear of the server or displayed on the ServerView Local Service
Display (for more information about the behavior of the Local Service Display,
see chapter
"Starting up and operation" on page 63
and the "Customer Self
Service (CSS)" manual on the ServerView Suite DVD 2).
