136 Operating Manual RX600 S5
Opening/Closing the server CSS components
©
c
ogn
it as
. G
e s e
lls
c h
ft f
ü r T
e
c h ni
k -D
o
k u m
e n
tat
ion m
b H
20
10
P
fa
d : C
:\ P
rogra
m
m
e \F
CT
\t im
_a
pp
\t im
_l
o
c a
l\ w
or
k \P
ICH
OL
\O
B
J _ D
O
K U
-4
8 9
1 -0
03
.f
m
8.3.2 Closing the server
V
CAUTION!
The housing cover must be replaced as soon as possible for purposes of
cooling, to comply with EMC regulations (regulations regarding
electromagnetic compatibility) and to prevent fires.
Figure 52: Placing the housing cover
– Place the housing cover onto the server such that it projects approx. 2 cm at
the back (see circle in figure above).
– Push the housing cover as far as possible in the direction of the arrow.
– Fasten the little screw (see circle in figure 51 ) on the cover.
