I/o fabric in 4p configuration – FUJITSU T5440 User Manual
Page 191
Performing Node Reconfiguration
169
I/O Fabric in 4P Configuration
Related Information
■
“System Bus Topology” on page 167
■
“I/O Fabric in 2P Configuration” on page 168
CMP Number
Devices Controlled
CMP0
Onboard disk drives
Onboard USB ports
Onboard DVD drive
PCIe0
PCIe1
CMP1
Onboard Gbit or 10-Gbit network
PCIe4
PCIe5
CMP2
PCIe2
PCIe3
CMP3
PCIe6
PCIe7
