150 SPARC Enterprise T5440 Server Service Manual • June 2011
2. Install the two No. 2 Phillips screws.
3. Plug the front control panel connector into the front I/O board.
4. Plug the front control panel connector into J9901 on the motherboard.
Next Steps
■ “Install the Fan Tray Carriage” on page 134
■ “Install a Fan Tray” on page 88
■ “Install the Top Cover” on page 154
■ “Install the Server Into the Rack” on page 154
■ “Connect the Power Cords to the Server” on page 157
■ “Power On the Server” on page 157
Servicing the Front I/O Board
The front I/O board contains two USB connectors. You must remove the front control
panel to service the front I/O board.
This topic includes the following:
■ “Remove the Front I/O Board” on page 150
■ “Install the Front I/O Board” on page 151
Related Information
■ “Infrastructure Boards and Cables” on page 1
■ “Front Panel Diagram” on page 3
■ “Servicing the Front Control Panel” on page 148
▼ Remove the Front I/O Board
Before you begin, complete these tasks:
■ Read the section, “Safety Information” on page 63 .
■ Power off the server, using one of the methods described in the section, “Powering
Off the System” on page 67 .
■ “Disconnect Power Cords From the Server” on page 68
