140 SPARC Enterprise T5440 Server Service Manual • June 2011
■ “Remove the Service Processor” on page 124
■ “Remove a CMP/Memory Module” on page 104
Note – You must remove all CMP and memory modules.
■ “Remove a Fan Tray” on page 87
Note – You must remove all four fan trays.
■ “Remove the Fan Tray Carriage” on page 133
1. Remove the CMP/memory module bracket.
The bracket is secured with six captive No. 2 Phillips screws. See “Motherboard
Fastener Locations” on page 143 .
