TX300 S6 Options Guide 99
10 Conversion from a floorstand
model to a rack model
V
CAUTION!
Follow the safety instructions in the chapter "Safety instructions" on
page 19 .
Ê Open the server and remove the front cover as described in the chapter
"Preparation" on page 27 .
I
The front cover is no longer required.
Ê Remove the screw on the server rear side that secures the right-hand side
cover to the server enclosure.
I
The right-hand side cover and the top cover build one part.
Figure 71: Removing the right-hand side cover
Ê Lift the hook up slightly using a screwdriver.
Ê Push the right-hand side cover in the direction of the arrow.
Ê Lift off the right-hand side cover.
I
The right-hand side cover is no longer required.
