TX300 S6 Options Guide 91
Expansion cards and BBU Installing a BBU
Figure 64: Inserting and fastening the cable cover
Ê Insert the cable cover in the recesses.
Ê Close the cable cover at the top.
Ê Make sure that the third guide engages in the recess of the cable guide (see
circle).
Ê Secure the cable cover with the knurled screw.
Ê Reinstall the fan carrier as described in the section "Installing the fan carrier"
on page 105 .
Ê Close the server, connect it to the power outlet, and switch it on as described
in the
chapter "Completion" on page 105 .
