TX300 S6 Options Guide 79
Expansion cards and BBU Installing a BBU
8.2 Installing a BBU
V
CAUTION!
● Do not connect the cable using excessive force, the connector is
weak.
● Follow the safety instructions in the chapter "Safety instructions" on
page 19 .
The Battery Backup Unit (BBU) backs up the memory contents of the SAS/SATA
RAID controller in the event of a power failure.
One BBU can be installed for each SAS/SATA RAID controller. A maximum of
three BBUs can be installed for each system.
Ê Open the server and remove the fan carrier as described in the chapter
"Preparation" on page 27 .
Figure 51: Removing the BBU carrier plate
Ê Loosen the screw and remove the BBU carrier plate from the housing.
