96
Options Guide
TX300 S6
USB Flash Module (UFM)
Further options
9.2
USB Flash Module (UFM)
The server can be equipped with a USB Flash Module (UFM).
Figure 68: UFM installation kit
Ê
Open the server as described in the
chapter "Preparation" on page 27
.
Figure 69: UFM - Position on the system board
1
USB Flash Module (UFM)
3
UFM spacer
2
UFM nylon screw
0
1
2
