Page 34
34
Options Guide
TX300 S6
Rack model
Preparation
4.2.2
Removing the rack front cover
You remove the rack front cover when making the following routines:
–
Installing/removing accessible drives
Figure 9: Removing the rack front cover
Ê
Remove two knurled screws on either side (1).
Ê
Remove the rack front cover to the front together with the plastic cover (2).
1
1
2
