102 Options Guide TX300 S6
Conversion from a floorstand model to a rack model
Ê Turn the dummy covers removed beforehand through 90° to the left.
Ê Install the drives and empty covers in the drive cage.
Ê Reestablish all connections to the drives.
Ê Attach the rack front cover as described in the section "Attaching the rack
front cover" on page 111 .
Ê Close the server as described in the section "Closing the server" on
page 112 .
Figure 75: Inserting the rail adapter (shown rail adapter left)
I
There are a left and a right rail adapter. Proceed the following three steps
for both sides of the server.
Ê Insert the rail adapter (1).
Ê Slide the rail adapter frontward (2) until the hooks (a) engage.
1
