28 Options Guide TX300 S6
Floorstand model Preparation
4.1 Floorstand model
I
For some expansions and conversions, it is advisable to lay the server
on its right-hand side and to remove the server feet.
4.1.1 Opening the server
Ê Terminate all applications and shut down the server correctly.
Ê If your operating system has not switched off the server, press the On/Off
button.
Ê Pull all power cords out of the power outlet.
Ê If required, remove the lock on the side cover.
Ê If necessary, lay the server on its right-hand side.
Get a second person to help you do this. The server can weigh around 25 -
40 kg (depending on the configuration).
Make sure that the server feet protrude over the table edge.
Figure 2: Removing the side cover
Ê Pull the locking lever as far as it will go (1). This pushes the side cover
backward (2).
Ê Remove the side cover (3).
ቤ
ባ
ቢ
