Chapter 1 - System Description
BreezeACCESS VL System Manual
30
1.7.5.5 25dBi Antenna (for B&B point-to-point link)
Table 1-22: 25dBi Antenna Specifications
Item Description
Regulatory Compliance ETSI EN 302 085 V1.1.2 (2001-02) Range1
Frequency Range 4.900-5.100 GHz
Gain 25dBi min.
Azimuth Beamwidth 6
°
Elevation Beamwidth 6
°
Polarization Linear (Vertical/Horizontal)
Dimensions (cm) 45 x 45 x 3
Weight (kg) 3 (max, excluding mounting kit)
Connector N-Type, Female
Mounting Kit 2.75”-3.5” pole, 0 to -10
° tilt, 2.2kg
1.7.5.6 SU-I-D Wall/Window Detached Antenna
Table 1-23: SU-I-D Wall/Window Detached Antenna Specifications
Item Description
Frequency Range 5.150-5.875 GHz
Gain 15dBi net (excluding cable loss).
Azimuth Beamwidth 45
o
~55°
Elevation Beamwidth 10°~12°
Polarization Linear (Vertical)
Dimensions (cm) 33 x 9.3 x 2.1
Weight (g) 190
Connector SMA jack
Cable 2 meter, 2 x SMA plug, 3.6 dB max insertion loss
