Chapter 1 - System Description
BreezeACCESS VL System Manual
24
1.7.5.1.2 Connectors
Table 1-12: Connectors, SU-A/E Subscriber Unit
Unit Connector Description
IDU ETHERNET 10/100BaseT Ethernet (RJ-45)
Cable connection to a PC: crossed
Cable connection to a hub: straight
RADIO 10/100BaseT Ethernet (RJ-45)
AC IN 3 pin AC power plug
SU-A-ODU INDOOR 10/100BaseT Ethernet (RJ-45), protected by a waterproof
sealing assembly
New SU-A-ODU
(5.4/5.8 GHz)
IDU COM 10/100BaseT Ethernet (RJ-45), protected by a sealing cap
SU-E-ODU INDOOR 10/100BaseT Ethernet (RJ-45), protected by a waterproof
sealing assembly
ANT N-Type jack, 50 ohm, lightning protected
New SU-E-ODU
(0.9 GHz)
IDU COM 10/100BaseT Ethernet (RJ-45), protected by a sealing cap
ANT N-Type jack, 50 ohm, lightning protected
1.7.5.1.3 Electrical
Table 1-13: Electrical Specifications, SU-A/E Subscriber Unit
Unit Details
General Power consumption: 25W
IDU AC power input: 85-265 VAC, 50-60 Hz
ODU 54 VDC from the IDU over the indoor-outdoor Ethernet cable
