Specifications
System Description
23
1.7.5 Physical and Electrical
1.7.5.1 SU-A/E Subscriber Unit
NOTE
In the 5.4 and 5.8 GHz band, the equipment may be shipped with a new, smaller size SU-A-ODU
that supports both horizontal and vertical polarization.
1.7.5.1.1 Mechanical
Table 1-11: Mechanical Specifications, SU-A/E Subscriber Unit
Unit Structure Dimensions (cm) Weight (kg)
General An IDU indoor unit and an ODU outdoor
unit with an integral antenna or a
connection to an external antenna
IDU PS1073 Plastic box (black), desktop or wall
mountable
14 x 6.6 x 3.5 0.3
SU-A-ODU Metal box plus an integral cut diamond
shaped antenna in a plastic enclosure,
pole or wall mountable
41.5 x 36.9 x 6.3 2.3
New SU-A-ODU
(5.4/5.8 GHz)
Diamond shaped metal box plus an
integral antenna in a plastic enclosure,
pole or wall mountable
22 x 22 x 7 1.3
SU-E-ODU Metal box, pole or wall mountable 30.5 x 11.7 x 5.7 1.8
New SU-E-ODU
(0.9 GHz)
Diamond shaped metal box plus a
plastic enclosure, pole or wall mountable
22 x 22 x 7 1.3
SU-Ant-0.9G-10 Pole mountable, elevation adjustable 30.5 x 30.5 x 2.5 1.3
