Specifications
System Description
27
1.7.5.3.2 Connectors
Table 1-17: Connectors, Modular Base Station Equipment
Unit
Connector
Description
BS-AU
10/100 BaseT
10/100BaseT Ethernet (RJ-45) with 2 embedded LEDs.
Cable connection to a PC: crossed
Cable connection to a hub: straight
RADIO
10/100BaseT Ethernet (RJ-45) with 2 embedded LEDs
AU-ODU
INDOOR
10/100BaseT Ethernet (RJ-45), protected by a waterproof
sealing assembly
ANT
N-Type jack, 50 ohm, lightning protected
BS-PS-AC
AC-IN
3-PIN AC power plug
BS-PS-DC
-48 VDC
3 pin DC D-Type 3 power pins plug
Amphenol 717TWA3W3PHP2V4RRM6
Antenna
RF
N-Type jack (on a 1.5m cable in the Omni-8-5.8)
1.7.5.3.3 Electrical
Table 1-18: Electrical Specifications, Modular Base Station Equipment
Unit
Details
General
240W max. for a fully equipped chassis (1 PS, 6 AU)
BS-PS-AC
AC power input: 85-265 VAC, 47-65 Hz
DC power output: 54 V; 3.3 V
BS-PS-DC
DC power input: -48 VDC nominal (-34 to -72), 10 A max
DC power output: 54 V; 3.3 V
BS-AU
3.3 VDC, 54 VDC from the power supply module(s) via the back plane
AU-ODU
54 VDC from the BS-AU over the indoor-outdoor Ethernet cable
AU-E-BS (IDU+ODU)
Power consumption: 30W
