Chapter 1 - System Description
BreezeACCESS VL System Manual
18
Table 1-7: Radio Specifications
Item Description
SU-I-D Detached Antenna 15 dBi typical net (excluding cable loss) in the 5.150-5.875 GHz
band, 45
o
~55° horizontal x 10°~12° vertical, vertical polarization,
RoHS compliant.
External Subscriber Antenna
for SU-E 0.9 GHz
10.5 dBi minimum in the 902-928 MHz band. 55
o
AZ x 60
o
EL,
vertical/horizontal polarization, RoHS compliant
AU Antennas (optional) „ AU-Ant-5G-16-60: 16 dBi typical, 5.150-5.875 GHz,
60
o
AZ x 10
o
EL sector antenna, vertical polarization, compliant
with ETSI EN 302 326-3 V1.2.1 (2007-01)
„ AU-Ant-5G-17-90: 17 dBi typical, 5.150-5.875 GHz,
90
o
AZ x 6
o
EL sector antenna, vertical polarization, compliant
with ETSI EN 302 326-3 V1.2.1 (2007-01)
„ AU-Ant-5G-15-120: 15 dBi typical, 5.150-5.875 GHz,
120
o
AZ x 6
o
EL sector antenna, vertical polarization, compliant
with ETSI EN 302 326-3 V1.2.1 (2007-01)
„ AU-Ant-4.9G-15-120: 15 dBi typical, 4.900-5.100 GHz,
124
o
AZ x 6.5
o
EL sector antenna, vertical polarization,
compliant with ETSI EN 302 326-3 V1.2.1 (2007-01)
„ AU-Ant-4.9G-9-Omni: 9 dB typical i, 4.900-5.100 GHz,
360
o
AZ x 8
o
EL, vertical polarization.
„ AU-Ant-5.4G-8-Omni: 8 dBi typical, 5.150-5.725 GHz,
360
o
AZ x 4.5
o
EL, vertical polarization.
„ AU-Ant-5.8G-8-Omni: 8 dBi typical, 5.725-5.875 GHz,
360
o
AZ x 9
o
EL, vertical polarization.
„ AU-Ant-5.8G-14-120-UK: 14dBi typical, 5.725-5.850 GHz,
120
o
AZ x 6.5
o
EL sector antenna, vertical polarization. The
antenna pattern complies with Ofcom’s IR 2007 EIRP profiles.
„ Ant-0.9G-V/H-10-90: 2x10dBi typical, 902-928 MHz, dual
vertical/horizontal polarization, 90 o AZ x 16 o EL for Vpol, 90 o AZ
x 19
o
EL for Hpol.
„ AU-Ant-0.9G-7-Omni: 7dBi typical, 902-928 MHz, 360 o
AZ x 17
o
EL, vertical polarization.
