Menus and Parameters
Operation and Administration
159
„ 1 – Automatic Noise Floor Selection: For optimizing only the noise floor level
„ 2 – Clear Channel Selection: For optimizing only the operating channel (AU
only)
„ 3 – Statistics Only: For performing only a spectrum analysis, without
modifying the operating channel or noise floor level
4.2.6.2.19.2 Advanced Settings
Use this menu to provide additional parameters that will refine the analysis
performed by the Interference Mitigation mechanism. You can ignore these
parameters, leaving their default settings in place. However, filling in as many of
them as possible, will optimize the process, providing better results.
4.2.6.2.19.2.1 AU Height
Indicates the height (in meters) of the AU antenna. It is useful for calculating the
distance.
The available range is from 15 to 200 (meters).
The default is 30 (meters).
4.2.6.2.19.2.2 AU/SU Antenna Gain
„ SU Antenna Gain: The antenna gain (in dBi) for a typical SU (AU only).
The available range is from 9 to 20 (dBi).
The default is 17 (dBi).
„ AU Antenna Gain: The antenna gain (in dBi) for the AU (SU only).
The available range is from 9 to 20 (dBi).
The default is 12 (dBi).
4.2.6.2.19.2.3 AU/SU Maximum Modulation
„ SU Maximum Modulation: The maximum modulation of the SUs in the link.
The available range is from 1 to 8.
The default is 5.
„ AU Maximum Modulation: The maximum modulation of the AU in the link.
The available range is from 1 to 8.
