Menus and Parameters
Operation and Administration
143
On VL 900 AUs with hardware revision G and VL 900 SUs with hardware revision
F, the transmit power cannot vary beyond certain thresholds. For this purpose,
the maximum transmission power is limited by the unit’s maximum modulation,
which sets the minimum transmission power level, according to regulations.
Table 4-5: Maximum TX power for VL 900 units
Max.
Modulation
TX power per modulation
8 7 6 5 4 3 2 1
8 19 dBm 20 dBm 22 dBm 24 dBm 24 dBm 24 dBm 24 dBm 24 dBm
7 20 dBm 22 dBm 24 dBm 26 dBm 26 dBm 26 dBm 26 dBm
6 22 dBm 24 dBm 26 dBm 27 dBm 27 dBm 27 dBm
5 24 dBm 26 dBm 27 dBm 27 dBm 27 dBm
4 26 dBm 27 dBm 27 dBm 27 dBm
3 27 dBm 27 dBm 27 dBm
2 27 dBm 27 dBm
1 27 dBm
4.2.6.2.8.1.2 Show Transmit Power Parameters
This option displays the Transmit Power parameter and the current transmit
power for the different modulation levels.
4.2.6.2.8.2 Maximum Transmit Power (SU only)
The Maximum Transmit Power submenu includes the following options:
„ Maximum Tx Power
„ Show Maximum Tx Power Parameters
4.2.6.2.8.2.1 Maximum Tx Power
The Maximum Tx Power parameter limits the maximum transmit power that can
be reached by the ATPC algorithm. It also sets the upper limits for the Transmit
Power parameters.
The minimum value for the Maximum Tx Power is -10 dBm. The maximum value
depends on several unit properties and parameters:
