Programming IDEC SmartRelay
84 IDEC SmartRelay Manual 
3.6.6 Switching IDEC SmartRelay to RUN mode
In the main menu, select RUN to start IDEC SmartRelay.
1. Return to the main menu:
Press ESC
2. Move the ’>’ cursor to ’Start’: Press or
3. Confirm ’Start’: Press OK
IDEC SmartRelay runs the circuit program and shows the
following display:
Display field of IDEC SmartRelay in RUN mode
2008-05-26
Mo 09:00
I:
0.. 123456789
1..0123456789
2..01234
Q:
0.. 123456789
1..0123456
AI:
1: 00000
2: 01000
3: 00253
AI:
4: 00010
5: 00000
6: 00005
Start screen: Date and current time-of-
day (only for versions with real-time
clock). This element flashes if the date
and time are not set.
Or: Start screen digital inputs (see
Chapter 5.2.5)
Press
Press
Press
Press
Press
Inputs I1 to I9
Inputs I10 to I19
Inputs I20 to I24
Outputs Q1 to Q9
Outputs Q10 to Q16
Analog inputs AI1 to AI3
Analog inputs AI4 to AI6
