Configuring IDEC SmartRelay
234 IDEC SmartRelay Manual 
5.1 Selecting parameter assignment mode
Press ESC to change from RUN to parameter assignment
mode:
2008-05-26
Mo 09:00
ESC
...Press
Note
The following applies to earlier device versions up to FL1A:
• You open parameter assignment mode by pressing
ESC+OK.
IDEC SmartRelay changes to parameter assignment mode
and opens the parameter assignment menu:
>Stop
Set Param
Set..
Prg Name
Description of the four menu items of the parameter assignment
menu
• Stop
You select this command to stop your circuit program and
thus change to the main menu of programming mode. To do
so:
1. To move the ’>’ cursor to ’Stop’:
Press or
2. To confirm ’Stop’: Press OK
Stop Prg
>No
Yes
3. To move the ’>’ cursor to ’Yes’: Press or
4. To confirm ’Yes’: Press OK
