TickType
Ch by Ch
B33 3+/
Tick Type: Character by Character
(Ch by Ch) or Line by Line (Ln by
Ln)
IDEC SmartRelay functions
IDEC SmartRelay Manual 201
5. If your message text has lines that tick, press to
position the cursor on the ”Ch by Ch” line and then press
or to select either ”Ch by Ch” or ”Ln by Ln” for the
TickType.
6. From the Tick T ype screen, press to enable or disable
ticking for each line of the message text. IDEC
SmartRelay displays the following screen form:
1 = No
2 = No
B33 4+/
Tick settings:
No: Line does not tick
Yes: Line does tick
7. Press or to choose between ”No” and ”Yes” to define
whether line 1 ticks.
8. Press to move the cursor to the second line, and press
or to choose between ”No” and ”Yes” for line 2. From
the last line press to go to the screen from for lines 3
and 4. Configure line ticking for lines 3 and 4 in the same
way as for lines 1 and 2.
3 = No
4 = No
B33 5+/
Tick settings:
No: Line does not tick
Yes: Line does tick
9. Press OK to confirm the complete message text
configuration.
Visible parameters or process variables
The following parameters or process variables can be
displayed in a message text, as either numerical values or
bar-graph representations of values:
