IDEC SmartRelay functions
IDEC SmartRelay Manual 189
Scaling an analog input value
You can influence the analog input value of a potentiometer
by interconnecting an analog input with an analog amplifier
and an analog memory marker.
• Scale the analog value at the analog amplifier for further
use.
• Connect, for example, the time base for parameter T of a
time function (e.g. On-/Off-delay, Chapter 4.4.3) or the on
and/or off limit specification of an up/down counter
(Chapter 4.4.13) to the scaled analog value.
For more information with programming examples refer to
the online help for WindLGC.
Setting the Par parameter
The gain and offset parameters are used to adapt the
sensors to the relevant application.
View in programming mode (example):
B3 +
A
=02.50
B =–00300
p =0
Gain
Decimals in the message text
Offset
View in parameter assignment mode (example):
B3
A
=02.50
B =–00300
AQ =–00250
