IDEC SmartRelay memory and battery cartridge (card)
254 IDEC SmartRelay Manual 
6.3 Copying data from IDEC SmartRelay to the
memory cartridge
To copy the circuit program to the memory cartridge or
combined memory/battery cartridge:
1. Insert the memory cartridge or combined memory/battery
cartridge into the slot.
2. Switch IDEC SmartRelay to programming mode (ESC /
>Stop).
>Program..
Card..
Setup..
Start IDEC SmartRelay main menu
3. The main menu opens. To select the ’Card’ command:
Press or
4. Press OK. The transfer menu opens.
> Card
Card
CopyProtect
= IDEC
SmartRelay
5. Move the ’>’ cursor to ’IDEC SmartRelay  Card’ (if
required): Press or
6. Press OK.
IDEC SmartRelay now copies the circuit program to the
memory cartridge or combined memory/battery cartridge. (If
the memory cartridge is from an incompatible FL1A..FL1C
version, IDEC SmartRelay displays this message: “Unknown
Card / Press ESC” .)
