Configuring IDEC SmartRelay
236 IDEC SmartRelay Manual 
5.1.2 Selecting the parameters
To select a parameter:
1. On the parameter assignment menu, select

’Set Param’: Press or
Stop
>Set Param
Set..
Prg Name
2. Confirm with OK.
B9 1
Press ESC
No Param
T =60:00s
Ta =06:00s
Block number
Display number for functions
with several displays
The value set at parameter T
(Time)
The current time in IDEC
SmartRelay
No parameters for editing:
Press ESC to return to the
parameter assignment menu
IDEC SmartRelay shows the first parameter. If no
parameter can be set, you can press ESC to return to the
parameter assignment menu.
3. Now, select the desired parameter: Press or or .
4. Select the parameter you want to edit, and press OK.
