Programming IDEC SmartRelay
IDEC SmartRelay Manual 89
Assigning block parameters
Now you set the off-delay time T:
1. Move the cursor to Par, if it not already at this position:
Press or
2. Switch to editing mode: Press OK
IDEC SmartRelay shows the parameters in the parameter
assignment window:
B2 +R
T =00:00s
“+” means:
The parameter is
shown and can be
modified in the
parameter assignment
mode.
“R” means:
Retentivity is enabled
for this block.
T: The block
parameter
B2 is a time
function
Time value Timebase
To change the time value:
• Press and to position the cursor.
• Press and to modify the value at the relevant
position.
• Confirm your entries with OK.
