Page 96: Setup msg config start

Programming IDEC SmartRelay

IDEC SmartRelay Manual



1. On the Text Display, press ESC to switch IDEC SmartRe-

lay from RUN mode to STOP mode. Text Display shows

the following menu:

>Stop
Set Param

Msg Config

Set..

2. Press OK. The Text Display shows you the following dis-

play:

Stop Prg
>No

Yes

3. Press to move the cursor to “Yes”, and press OK. Enter

the correct password (in this case: “ZZ”). If you enter an

incorrect password, the Text Display returns to the dis-

play in Step 1.

Password?
ZZ

4. Press OK to exit the password entry screen form. The

Text Display opens the main menu:

>Setup
Msg Config

Start

IDEC SmartRelay changes to STOP mode.
