MS278XB OM 4-1
Chapter 4 — Front Panel Menus
4-1 Introduction
This chapter provides a comprehensive collection of annotated front panel menus and displays . Each
illustration is accompanied with a description that includes information on how to use the functions available
in that particular display. Additional navigation options and techniques may also be provided; however, this
chapter does not provide measurement concepts. For details on making measurements, refer to Chapter 5.
4-2 Quick Reference
This section contains a comprehensive list of menus with references to the page where a full description can be
found. Table 4-1 contains a list of main menus and submenus; Table 4-2 contains a list of property sheets and
dialog menus.
Table 4-1. List of Menus
Main Menu Submenu Page
Frequency Main Menu
Frequencies Menu 4-5
Step Size and Offset Menu 4-6
Amplitude Main Menu
Amplitude Menu 4-8
Y-Axis Options Menu 4-9
Bandwidth Main Menu
Bandwidth Menu 4-11
Auto Coupling Menu 4-12
Marker Main Menu
Marker Select Menu 4-14
Marker to (–>) Menu 4-17
Marker Config Menu 4-18
Display Lines Menu 4-18
Measurement Main Menu Measurement Menu 4-20
Trace Main Menu Trace Config Menu 4-24
Display Main Menu
Display Options Menu 4-26
Touch Screen Menu 4-26
Sweep Main Menu Sweep Menu 4-28
Trigger Main Menu Trigger Menu 4-30
System Main Menu
Rear Panel Control Menu 4-32
Calibration Menu 4-32
System Information Menu 4-32
Configuration Menu 4-33
Remote Control Menu 4-33
Service Menu 4-34
File Main Menu File Menu 4-35
