Measurements Operation Verification
MS278XB OM 5-71
5-6 Operation Verification
This section provides procedures that you can use to verify the signal analyzer is operating properly and meets
some of its specifications. You may perform the following verifications:
• Reference Oscillator Aging Rate (Optional)
• Frequency Readout Accuracy
• Frequency Span Accuracy
• Swept Resolution Bandwidth
• Single Sideband Phase Noise
• Average Noise Level
• Frequency Response
• Reference Level Switching Uncertainty
• Resolution Bandwidth (RBW) Switching Uncertainty
• Residual Spurious Response
• Input-related Spurious Response
Refer to the Required Equipment list before beginning these verification procedures.
Required Equipment
Table 5-2 lists the equipment used throughout the verification procedures.
Note: Specifications listed in this section are for reference only and should be verified with the Signature
Datasheet, part number: 11410-00396. The most current revision can be downloaded from the Documents
area of the Anritsu Internet site:
http://www.us.anritsu.com
Table 5-2. Required Equipment
Instrument Critical Specification Recommended Manufacturer/Model
Frequency Standard Frequency: 10 MHz
Accuracy: 5
×
10
–12
parts/day
Symmetricom Model 9390-9600
Synthesized Signal
Generator Frequency Range: 10 MHz to 8 GHz
Ultra Low Phase Noise Anritsu Model MG3691B with
Options 2A, 3, 4, 16
Synthesized Signal
Generator Frequency Range: 10 MHz to 6 GHz
Spurious Performance <–85 dBc HP 8665B
Adapter N(m) to K(f) Anritsu Model 34NKF50
Adapter Ruggedized K(m) to N(f) Anritsu Model 34RKNF50
Attenuator
K(m) to K(f)
Frequency Range: DC to 8 GHz
Attenuation: 3 dB
Anritsu Model 43KB-3
Attenuator
N(m) to N(f)
Frequency Range: DC to 8 GHz
Attenuation: 3 dB Weinschel Model 1-3
Attenuator
N(m) to N(f)
Frequency Range: DC to 8 GHz
Attenuation: 10 dB Weinschel Model 4410
Cable
N(m) to N(m)
Frequency Range: DC to 8 GHz
Impedance: 50
Ω
Any
