Measurements Measurement Examples
MS278XB OM 5-19
5-3 Measurement Examples
The examples in this section give a simple step-by-step instruction on how to set up the MS278XB to perform
the measurement and show a final screen shot of the measurement result.
The following example measurements are shown:
• Measuring a CW Carrier
• Measuring Harmonics
• Displaying Wide Band FFT Mode
• Displaying Narrow Band FFT Mode
• Measuring a Pulse in the Time Domain
• Displaying Trace Modes
• Displaying Detectors
• Measuring Phase Noise
It is assumed that you have read the previous section, Basic Measurement Setups, and are familiar with the
instrument’s menus and measurement setup procedures.
Note: All RF measurements apply only to the active trace.
