Operation Verification Measurements
5-92 MS278XB OM
13. Record the new marker level readout value on the display to the corresponding cell in Table 5-12.
14. Calculate the amplitude deviation by subtracting the new marker value from the 30 kHz RBW
marker reading.
15. Verify that the amplitude deviation is < 0.1 dB.
16. Repeat steps 11 through 16 for the rest of RBW and SPAN combinations in Table 5-12.
Table 5-12. Resolution Bandwidth Switch Uncertainty Test
RBW SPAN
MS2781B Marker
Reading
Amplitude Deviation
from 30 kHz RBW (dB) Specifications
10 Hz 10 kHz 0.15 dB
100 Hz 1 kHz 0.15 dB
300 Hz 5 kHz 0.15 dB
3 kHz 30 kHz 0.15 dB
10 kHz 100 kHz 0.15 dB
30 kHz 500 kHz 0.15 dB
100 kHz 1 MHz 0.15 dB
300 kHz 5 MHz 0.15 dB
1 MHz 10 MHz 0.15 dB
3 MHz 50 MHz 0.15 dB
