11. Robot Language Explanation
------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------
11 - 22
11.2.6.2 ARCOF Command
11.2.6.3 ARCCUR Command
11.2.6.4 ARCVOL Command
Description Outputs the Welding End Command.
Syntax
ARCOF
ARCOF AEF#=
ARCOF C=, {V= | VP=}
[,T=] [,ANTSTK]
File
Number
Arithmetic Equation. Number of welding end condition
file.
Rounded. 1∼32
Current
Output
Value
Arithmetic Equation. Welding current output
value(0∼500)
Unit: A Rounded
Voltage
Output
Value
Arithmetic Equation. Welding voltage output value
(Separate power source) (0∼40)
Unit: V [0.0]
Voltage
Rate
Arithmetic Equation. Voltage output rate about the
appropriate welding voltage (Single power source)
(0∼100)
Unit: % Rounded
Time
Arithmetic Equation. The delay time of the robot body
before the ARC Off. (0∼10) Unit: sec
[0.00]
Parameter
ANTSTK Automatic Anti-Stick feature
example
ARCOF AEF#=1
ARCOF C=300, V=V10!, T=1.00, ANTSTK
Comment
The result for each usage is as follows;
1. ARCOF : Welding ends as previously set by the condition with ARCCUR, ARCVOL
commands.
2. ARCOF : Welding ends as set by the conditions of the condition file.
3. ARCOF : Welding ends as set by the conditions of the parameters.
Description Sets the welding current output value with the set value.
Syntax ARCCUR C=
Parameter Current Output Value
Arithmetic Equation. Welding current
output value (0∼500) Unit: A
Rounded.
example ARCCUR C=200
Description Sets the welding voltage output value with the set value
Syntax ARCVOL {V= | VP=}
Voltage Output
Value Arithmetic Equation. Welding voltage output
value (0∼40)
Unit: V [0.0]
Parameter
Voltage Rate
Arithmetic Equation. The voltage rate about
the appropriate welding voltage (Single power
source) (0∼100)
Unit: %
Rounded.
example ARCVOL V=30
