6. System setting
------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------
6 - 28
6.2.1.10.2 Input source selection
Outline
It sets up from which of the hard wired or field bus the input receives.
Screen display
Reference
⑴ All initialize : All of input source selection modify standard or Fbus at one time.
The following massage is displayed if “ All Form” [PF1] select.
„ All of input source of the screen change if press [SET]key after
standard[0] input.
„ All of input source of the screen change if press [SET]key after field bus
[1] input.
⑵ Page initial : The page that describes on the present screen change the standard
or Fbus. The following massage is displayed if you select "Pg
Form” [PF2].
14:39:38 * Select Input Source *A:0 S:4
Select Input Source
0 DI1 - DI8 <- <
HWrd ,Fbus>
1 DI9 - DI16 <- < HWrd ,Fbus>
2 DI17 - DI24 <- < HWrd ,Fbus>
3 DI25 - DI32 <- < HWrd ,Fbus>
4 DI33 - DI40 <- < HWrd ,Fbus>
5 DI41 - DI48 <- < HWrd ,Fbus>
6 DI49 - DI56 <- Fbus >
7 DI57 - DI64 <- Fbus >
Page 1/4
[SHIFT]+[<-][->] to select input src
>
All Form Pg Form Previous Next Done
All Init.?Hardwiring:0,Fieldbus:1(0 - 1)
>[0 - 1]
All Form Pg Form Previous Next Done
Pg Form .?Hardwiring:0,Fieldbus:1(0 - 1)
>[0 - 1]
All Form Pg Form Previous Next Done
