6. System setting
------------------------------------------------------------------------------------------------
----------------------------------------------------------------------------------------
6 - 79
6.4.1.3.3 Welding sequence
Outline
It is a data that decides the welding sequence of controller in the playback of
the spot welding.
Screen display
Contents of the screen
Number : It is the number that designates in the spot welding function and there
are 64 unit.
Condition signal : It designates whether to output the welding condition signal
or not. Currently, this item is fixed to
Pressurization signal : It designates whether to output the pressurization signal
or not. Currently, this item is fixed to
Weld signal : It designates whether to output the weld signal or not. Currently,
this item is fixed to
WI wait : It designates whether to do the welding completion wait or not after
outputting the weld signal. Currently, this item is fixed to
Weld wait time : It designates the wait time of welding completion signal after
outputting the weld signal. The 0.0 is the infinite wait.
Welding completion wait time : It designates the wait time of until the gun opens
after completing the welding. But in case that the gun open time is short, the
14:39:38 *** Weld Sequence *** A:0 S:4
Number =[
1
]
Condition signal =< DSBL,
ENBL
>
Squeeze signal =<
DSBL
,ENBL >
Welding command signal =< DSBL,
ENBL
>
WI wait =< DSBL,
ENBL
>
Welding wait time =[0.00]
Welding end wait time =[0.00]
Select and Enter number. Press [SET]
>[1 - 64]
