Page 36 Operating Instructions Powador XP500/550-OD-TL
S t o r a g e / I n s t a l l a t i o n / S t a r t - u p
5.8.2 Software upgrade
If an update is available (for example, when new functions are added), use the SD card to update the inverter
software.
Update the HMI software
Perform the following steps in the indicated sequence:
 Copy the software image fi le (*.img) to the Root directory in the SD card.
 Once the copy is complete, Change the name of the image fi le to the following text.
- HMI: ‘XP_HMI_SW.img’ (*Name must be the same as above.)
 Insert the SD card into the HMI.
 The start buzzer indicating HMI Software Upgrade after a few seconds will beep twice as long.
 After the upgrade of about 2 ~ 3 minutes is complete, the system is restarted.
 When the upgrade is successful, the short buzzer will sound three times as short.
 If the upgrade fails, the short buzzer will sound eight times as short.
DANGER
Never turn off the power of the HMI and don’t remove the SD card until software
upgrade automatically start and complete.
When power is interrupted or SD card removed during the software upgrade, HMI
can not boot normally.
Update the C6x software
Perform the following steps in the indicated sequence:
 Copy the software fi le (*.hex) to the Root directory in the SD card.
 Once the copy is complete, Change the name of the image fi le to the following text.
- XCU: ‘XP_XCU_SW.hex’ (*Name must be the same as above.)
 Insert the SD card into the HMI.
 The start buzzer indicating XCU Software Upgrade after a few seconds will beep three time as long.
 After the upgrade of about 5 minutes is complete.
 When the upgrade is successful, the short buzzer will sound three times as short.
 If the upgrade fails, the short buzzer will sound eight times as short.
