Operating Instructions Powador XP500/550-OD-TL Page 31
S t o r a g e / I n s t a l l a t i o n / S t a r t - u p
Fault If a fault occurs during operation, the system stops. The system resets the
fault and tries to remove the fault. In the case that system removes a fault
successfully, system restarts all by itself. The system tries to remove the fault
at intervals of “MPPT Start” parameter since the last try until trial count
reaches to the number set in an “Auto Fault Reset Count” parameter. After
the number reaches to the “Auto Fault Reset Count” parameter, the system
will log an error and the system will not try to restart. In this case, XP500/550-
OD-TL inverter will try to remove the fault again using key Switch On com-
mand (after turning off by key Switch).
Table 4: Operating states
NOTE
If The System doesn’t try to remove the fault, please contact our service hotline.
