200 Programming: Tools
5.2 T
ool data
There are two ways to run a tool usage test for a pallet file:
 The highlight is on a pallet entry in the pallet file:
The TNC runs the tool usage test for the entire pallet
 The highlight is on a program entry in the pallet file:
The TNC runs the tool usage test for the selected program
BLOCK Block number in which the TOOL CALL block
was programmed
PATH  TOKEN = TOOL: Path name of the active main
program or subprogram
 TOKEN = STOTAL: Path name of the
subprogram
T Tool number with tool index
OVRMAX Maximum feed rate override that occurred
during machining. During Test Run the TNC
enters the value 100 (%)
OVRMIN Minimum feed rate override that occurred
during machining. During Test Run the TNC
enters the value –1
NAMEPROG  0 : The tool number is programmed
 1 : The tool name is programmed
Column Meaning
