Operation Programmer Operating Modes
Page 5-18 MDE-4524A Vehicle Module Programming Manual· May 2006
3 Select 1 to allow the Programmer to calculate the correct ratio.
YES
ENTER
1
MILEAGE ONLY - 0
COUNT RATIO -1 1
4 Press YES to accept the calculated ratio. Proceed to Download New Calibration Data to VM .
YES
ENTER
RAT 008000.0 OLD
? 007281.0 NEW
Download New Calibration Data to VM
1 Hold the Programmer near the vehicle's T-Ring.
HOLD PROGRAMMER
NEAR TANK RING
2 When communication is established, a series of beeps will be heard. Continue to hold the
Programmer near the T-Ring. Programming takes about 5 seconds.
TRANSMITTING
PLEASE WAIT
3 When complete, you will hear a long beep.
TRANSMISSION
COMPLETE
4 The Programmer turns off automatically.
Diagnostic Mode
The Diagnostic function reads a programmed VM and displays it as a string of data. It is the
easiest way to verify if the VM is transmitting. Follow this example.
1 Turn on the Programmer. Refer to “Turning On Programmer” on page 5-1 .
2 Select Diagnostic mode.
YES
ENTER
1 - PROG 2 - EDIT
3 - CAL 4 - DIAG ?
4
GHI
