LCS-4 L-Band Combiner Switch Revision 1
Remote Control Operation MN/LCS4.IOM
A-19
Parameter
Type
Command
(Instruction
Code and
qualifier) Arguments
for Cmd or
Response
to Query
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Target to
Controller) Query
(Instruction
code and
qualifier)
Response to query
(Target to Controller)
Switch
Global
Configuration SGC= 56 bytes,
with
numerical
entries fixed
value
entries, and
delimiters
Command or Query. Global configuration of Unit, in
the form:
SGC=abcdeffgghijklmmnnoopqrssstuvwxy’cr’’lf]
where:
a = Tx LCS Function (STT)
b = BUC A Power Supply Enable (BSA)
c = BUC B Power Supply Enable (BSB)
d = BUC A Reference Osc. Enable (BRA)
e = BUC B Reference Osc. Enable (BRB)
ff = BUC A Current Window (BCA)
gg = BUC B Current Window (BCB)
h= BUC Fault Logic (BFL)
i = RX LCS Function (SRL)
j = LNB A Power Supply Enable (LSA)
k = LNB B Power Supply Enable (LSB)
l = LNB A Reference Osc. Enable (LRA)
m = LNB B Reference Osc. Enable (LRB)
nn = LNB A Current Window (LCA)
oo = LNB B Current Window (LCB)
p = LNB Fault Logic (LFL)
q = Ref Source select (RSS)
r = VCXO Power Control (VPC)
sss = Reference OSC. Adjust. (SRO)
t= Reference Fault Logic (RFL)
u = Cold Start Enable (CLD)
v = Redundancy Switch Control Mode (RAM)
w = Redundancy Switch Control Mode (MOD)
x = UPC Support (UPC)
y = Modem FSK control (FSM)
SGC= (message ok)
SGC? (received ok,
but invalid
arguments found) SGC?
SGC=
abcdeffgghijklmmnnoopqrssstuvw
xy
(same format as command
arguments)
