LCS-4 L-Band Combiner Switch Revision 1
Block Up Converter MN/LCS4.IOM
5.2.2 A
SSEMBLE
BUC M
OUNTING
K
IT
(KT/9826-1)
Part No. Nomenclature QTY
FP/BR10351-1 Bracket, Mounting 1
FP/BR10352-1 Bracket, Mounting 2
FP/WG0034 Termination, Small Fins 1
FP/WG10359-1 Waveguide 3.75X2 2
GA/GSKTCP137FULL Gasket, Full Thickness, CP137 6
GA/GSKTCP137HALF Gasket, Half Thickness, CP137 1
HW/1/4-20HEXNUT Nut, Hex 2
HW/1/4-20X1/2SHSC Screw, SS 4
HW/1/4-FLT Washer, Flat 4
HW/1/4-SPIT Washer, Split 4
HW/10-SPLIT Washer, Split 4
HW/10-32X5/8SHSC Screw, Socket Cap 32
HW/10-FLT Washer, Flat 36
HW/10-SPLIT Washer, Split 36
HW/M4FLAT Washer, Flat 6
HW/M4LOCK Washer, Split 6
HW/M4X.07X8MMPHMS Screw, Panhead 6
SW-WGS+48V-137SB Switch, Waveguide CPR137G 1
IMPORTANT
Refer to BUC manufacturer’s documentation for installation on the
Comtech EF Data assembly.
1. Assemble brackets (FP/BR10352-2) on bracket FP/BR10351-1) and secure with two
bolts, flat washers, split washers, and two nuts.
2. Place gaskets on waveguides.
3. Install assembled waveguide to C-Band BUCs and secure using six screws, flat
washers, and split washers.
4. Place BUCs on bracket (FP/BR10351-1) and secure with screws. Flat washers, and
split washers.
5–3
