LCS-4 L-Band Combiner Switch Revision 1
Remote Control Operation MN/LCS4.IOM
A-17
Parameter
Type
Command
(Instruction
Code and
qualifier) Arguments
for Cmd or
Response
to Query
Description of Arguments
Note that all arguments are ASCII
numeric codes between 48 and 57.
Response to
Command
(Target to
Controller) Query
(Instruction
code and
qualifier)
Response to query
(Target to Controller)
Concise
Utility Status N/A 32 bytes,
alpha
numerical Query only.
Used to Query the Utility status of the LCS-4 response
in comma delimited.
Example:
CUS=aaaaa,bbbbb,ccc.c,ddd.d,eee,f,g,h,’cr’’lf’]
where:
aaaaa = BUC A CAL Current
bbbbb = BUC B CAL Current
ccc.c = LNB A CAL Current
ddd.d = LNB B CAL Current
eee = Reference Adjust setting
f = External Reference Sense
g = BUC Online Status
h = LNB Online Status
N/A CUS? CUS=x….x (see description for
details of arguments)
Retrieve
Alarm Status N/A 147 bytes,
text Query only.
Used to Query the Alarm status of the LCS-4
Example: RAS=’cr’
48VLT=OK’cr’
12VP1=OK’cr’
12VP2=OK’cr’
P5VLT=OK’cr’
N5VLT=OK’cr’
BUCAV=OK’cr’
BUCBV=OK’cr’
BUCAC=OK’cr’
BUCBC=OK’cr’
BUCSW=OK’cr’
LNBAV=OK’cr’
LNBAC=OK’cr’
LNBBC=OK’cr’
LNBSW=OK’cr’
FANMC=OK’cr’
REFLD=OK’cr’
BUCSW=OK’cr’
LNBSW=OK’cr’
SFLTS=ok’cr’’lf’]
N/A RAS? RAS=x….x (see description for
details of arguments)
